141276.00, 10 & 7.50 HP, 3 Ph, 60 & 50 Hz, 230/460 & 190/380 V, 1800 & 1500 RPM, 215JM Frame, TEFC, Washdown Pump Motor, C215T17WK17A

141276.00, 10 & 7.50 HP, 3 Ph, 60 & 50 Hz, 230/460 & 190/380 V, 1800 & 1500 RPM, 215JM Frame, TEFC, Washdown Pump Motor, C215T17WK17A

$2,786.48
(No reviews yet) Write a Review
SKU:
141276
Output HP:
10 & 7.50 Hp
Output KW:
7.5 & 5.6 kW
Voltage:
230/460 & 190/380 V
Phase:
3
Speed (RPM):
1760 & 1475 rpm
Frame Size:
215JM
Mounting:
Rigid Base
Enclosure:
Totally Enclosed Fan Cooled
Product Drawings1:
141276.00.pdf
Manufacture:
Marathon
Adding to cart… The item has been added

Nameplate Specifications

Phase: 3 Output HP: 10 & 7.50 Hp
Output KW: 7.5 & 5.6 kW Voltage: 230/460 & 190/380 V
Speed: 1760 & 1475 rpm Service Factor: 1.15 & 1.15
Frame: 215JM Thermal Protection: No Protection
Efficiency: 91.7 & 89.5 % Ambient Temperature: 40 °C
Frequency: 60 & 50 Hz Current: 26.4/13.2 & 27.4/13.7 A
Power Factor: 77.5 Duty: Continuous
Insulation Class: F Design Code: B
KVA Code: H Drive End Bearing Size: 6209
Opp Drive End Bearing Size: 6207 Enclosure: Totally Enclosed Fan Cooled
UL: Recognized CSA: Y
CE: Y IP Code: 56
Number of Speeds: 1
!
