Y317, 20 & 15 HP, 3 Ph, 60 & 50 Hz, 230/460 & 190/380 V, 1800 & 1500 RPM, 256TZ Frame, DP, Agricultural Motor, 256TTDBD6327

Y317, 20 & 15 HP, 3 Ph, 60 & 50 Hz, 230/460 & 190/380 V, 1800 & 1500 RPM, 256TZ Frame, DP, Agricultural Motor, 256TTDBD6327

$2,435.12
(No reviews yet) Write a Review
SKU:
Y317
Output HP:
20 Hp
Output KW:
14.9 kW
Voltage:
230/460 V
Phase:
3
Speed (RPM):
1770 rpm
Frame Size:
256TZ
Mounting:
Rigid Base
Enclosure:
Drip Proof
Product Drawings1:
Y317.pdf
Manufacture:
Marathon
Adding to cart… The item has been added

Nameplate Specifications

Phase: 3 Output HP: 20 & 15 Hp
Output KW: 14.9 & 11.2 kW Voltage: 230/460 & 190/380 V
Speed: 1770 & 1475 rpm Service Factor: 1.15 & 1.15
Frame: 256TZ Thermal Protection: No Protection
Efficiency: 93 & 92.4 % Ambient Temperature: 40 °C
Frequency: 60 & 50 Hz Current: 48.5/24.3 & 45/22.4 A
Power Factor: 83.5 Duty: Continuous
Insulation Class: F Design Code: B
KVA Code: G Drive End Bearing Size: 6309
Opp Drive End Bearing Size: 6208 Enclosure: Drip Proof
UL: Recognized CSA: Y
CE: Y IP Code: 22
Number of Speeds: 1
!
