W517A-P, 3 HP, 3 Ph, 60 Hz, 460 V, 3600 RPM, 182T Frame, TENV, XRI®-841 Severe Duty Motor, 182THTCD9002

W517A-P, 3 HP, 3 Ph, 60 Hz, 460 V, 3600 RPM, 182T Frame, TENV, XRI®-841 Severe Duty Motor, 182THTCD9002

$1,014.43
(No reviews yet) Write a Review
SKU:
W517A-P
Output HP:
3 Hp
Output KW:
2.2 kW
Voltage:
460 V
Phase:
3
Speed (RPM):
3527 rpm
Frame Size:
182T
Mounting:
Rigid Base
Enclosure:
Totally Enclosed Non Ventilated
Product Drawings1:
W517A-P.pdf
Manufacture:
Marathon
Adding to cart… The item has been added

Nameplate Specifications

Phase: 3 Output HP: 3 Hp
Output KW: 2.2 kW Voltage: 460 V
Speed: 3527 rpm Service Factor: 1.15
Frame: 182T Thermal Protection: No Protection
Efficiency: 89.5 % Ambient Temperature: 40 °C
Frequency: 60 Hz Current: 3.5 A
Power Factor: 89 Duty: Continuous
Insulation Class: H Design Code: B
KVA Code: K Drive End Bearing Size: 6206
Opp Drive End Bearing Size: 6205 Enclosure: Totally Enclosed Non Ventilated
UL: Recognized CSA: Y
CE: Y IP Code: 56
Number of Speeds: 1
!
