U876B, 50 & 40 HP, 3 Ph, 60 & 50 Hz, 230/460 & 190/380 V, 1800 & 1500 RPM, 326T Frame, TEFC, XRI퉌¬-SD Severe Duty Motor, 326TTFCD16574

U876B, 50 & 40 HP, 3 Ph, 60 & 50 Hz, 230/460 & 190/380 V, 1800 & 1500 RPM, 326T Frame, TEFC, XRI퉌¬-SD Severe Duty Motor, 326TTFCD16574

Marathon Electric

$5,166.03
(No reviews yet) Write a Review
SKU:
U876B
Output HP:
50 Hp
Output KW:
37 kW
Voltage:
230/460 V
Phase:
3
Speed (RPM):
1782 rpm
Frame Size:
326T
Mounting:
Rigid Base
Enclosure:
Totally Enclosed Fan Cooled
Product Drawings1:
U876B.pdf
Manufacture:
Marathon
MAP Policy:
Yes
Adding to cart… The item has been added

Add to Cart for Discount

Nameplate Specifications

Phase: 3 Output HP: 50 & 40 Hp
Output KW: 37.0 & 30.0 kW Voltage: 230/460 & 190/380 V
Speed: 1782 & 1482 rpm Service Factor: 1.15 & 1.15
Frame: 326T Thermal Protection: No Protection
Efficiency: 94.5 & 93.9 % Ambient Temperature: 40 °C
Frequency: 60 & 50 Hz Current: 117/58.5 & 114/57 A
Power Factor: 85 Duty: Continuous
Insulation Class: H Design Code: B
KVA Code: G Drive End Bearing Size: 6312
Opp Drive End Bearing Size: 6212 Enclosure: Totally Enclosed Fan Cooled
UL: Recognized CSA: Y
CE: Y IP Code: 55
Number of Speeds: 1



!
