GT1111A, 3 HP, 3 Ph, 60 Hz, 575 V, 1200 RPM, 213T Frame, TEFC, Globetrotter® General Purpose Motor, 213TTFCD6080

GT1111A, 3 HP, 3 Ph, 60 Hz, 575 V, 1200 RPM, 213T Frame, TEFC, Globetrotter® General Purpose Motor, 213TTFCD6080

$846.68
(No reviews yet) Write a Review
SKU:
GT1111A
Output HP:
3 Hp
Output KW:
2.2 kW
Voltage:
575 V
Phase:
3
Speed (RPM):
1185 rpm
Frame Size:
213T
Mounting:
Rigid Base
Enclosure:
Totally Enclosed Fan Cooled
Product Drawings1:
GT1111A.pdf
Manufacture:
Marathon
Adding to cart… The item has been added

Nameplate Specifications

Phase: 3 Output HP: 3 Hp
Output KW: 2.2 kW Voltage: 575 V
Speed: 1185 rpm Service Factor: 1.15
Frame: 213T Thermal Protection: No Protection
Efficiency: 89.5 % Ambient Temperature: 40 °C
Frequency: 60 Hz Current: 3.5 A
Power Factor: 73 Duty: Continuous
Insulation Class: F Design Code: A
KVA Code: L Drive End Bearing Size: 6308
Opp Drive End Bearing Size: 6208 Enclosure: Totally Enclosed Fan Cooled
UL: Listed CSA: Y
CE: Y IP Code: 55
Number of Speeds: 1 Hazardous Location: DIVISION 2 T2B



!
