Nameplate Specifications
| Phase: | 3 | Output HP: | 75 Hp |
| Output KW: | 56.0 kW | Voltage: | 230/460 V |
| Speed: | 1780 rpm | Service Factor: | 1 |
| Frame: | 365T | Enclosure: | Totally Enclosed Fan Cooled |
| Thermal Protection: | Thermostat | Efficiency: | 94.1 % |
| Ambient Temperature: | 40 °C | Frequency: | 60 Hz |
| Current: | 184.0/92.0 A | Power Factor: | 82 |
| Duty: | Continuous | Insulation Class: | H |
| Design Code: | INV | KVA Code: | J |
| Drive End Bearing Size: | 6314 | Opp Drive End Bearing Size: | 6312 |
| UL: | Recognized | CSA: | Y |
| CE: | Y | IP Code: | 43 |
| Number of Speeds: | 1 |
