W622A, 200 HP, 3 Ph, 60 Hz, 460 V, 1200 & 1200 RPM, 449T Frame, TEFC, XRI®-841 Severe Duty Motor, 449THFCD9088

W622A, 200 HP, 3 Ph, 60 Hz, 460 V, 1200 & 1200 RPM, 449T Frame, TEFC, XRI®-841 Severe Duty Motor, 449THFCD9088

$23,501.47
(No reviews yet) Write a Review
SKU:
W622A
Output HP:
200 Hp
Output KW:
149 kW
Voltage:
460 V
Phase:
3
Speed (RPM):
1190 rpm
Frame Size:
449T
Mounting:
Rigid Base
Enclosure:
Totally Enclosed Fan Cooled
Product Drawings1:
W622A.pdf
Manufacture:
Marathon
Adding to cart… The item has been added

Nameplate Specifications

Phase: 3 Output HP: 200 Hp
Output KW: 149 kW Voltage: 460 V
Speed: 1190 rpm Service Factor: 1.15
Frame: 449T Thermal Protection: No Protection
Efficiency: 95.8 % Ambient Temperature: 40 °C
Frequency: 60 Hz Current: 230 A
Power Factor: 85 Duty: Continuous
Insulation Class: H Design Code: B
KVA Code: G Drive End Bearing Size: NU319
Opp Drive End Bearing Size: 6317 Enclosure: Totally Enclosed Fan Cooled
!
