Nameplate Specifications
| Phase: 3 | Output HP: 30 Hp |
| Output KW: 22.4 kW | Voltage: 190/380-400 V |
| Speed: 3560 rpm | Service Factor: 1.15 |
| Frame: 284TS | Thermal Protection: No Protection |
| Efficiency: 91 % | Ambient Temperature: 50 °C |
| Frequency: 60 Hz | Current: 87.0/43.5-41.0 A |
| Power Factor: 86 | Duty: Continuous |
| Insulation Class: F | Design Code: B |
| KVA Code: F | Drive End Bearing Size: 6211 |
| Opp Drive End Bearing Size: 6211 | Enclosure: Drip Proof |
| UL: Listed | CSA: Y |
| CE: Y | IP Code: 23 |
| Number of Speeds: 1 |
