U041A, 2 & 1.50 HP, 3 Ph, 60 & 50 Hz, 230/460 & 190/380 V, 1200 & 1000 RPM, 184T Frame, EPFC, Hazardous Duty퉌¬ Explosion Proof Motor, 184TTGN6576

U041A, 2 & 1.50 HP, 3 Ph, 60 & 50 Hz, 230/460 & 190/380 V, 1200 & 1000 RPM, 184T Frame, EPFC, Hazardous Duty퉌¬ Explosion Proof Motor, 184TTGN6576

Marathon Electric

$1,117.11
(No reviews yet) Write a Review
SKU:
U041A
Output HP:
2 Hp
Output KW:
1.5 kW
Voltage:
230/460 V
Phase:
3
Speed (RPM):
1175 rpm
Frame Size:
184T
Mounting:
Rigid Base
Enclosure:
Explosion Proof Fan Cooled
Product Drawings1:
U041A.pdf
Manufacture:
Marathon
MAP Policy:
Yes
Adding to cart… The item has been added

Add to Cart for Discount

Nameplate Specifications

Phase: 3 Output HP: 2 & 1.50 Hp
Output KW: 1.5 & 1.1 kW Voltage: 230/460 & 190/380 V
Speed: 1175 & 975 rpm Service Factor: 1.15 & 1.15
Frame: 184T Thermal Protection: Thermostat
Efficiency: 88.5 & 87.5 % Ambient Temperature: 40 °C
Frequency: 60 & 50 Hz Current: 6/3 & 5.6/2.8 A
Power Factor: 70 Duty: Continuous
Insulation Class: F Design Code: B
KVA Code: K Drive End Bearing Size: 6206
Opp Drive End Bearing Size: 6206 Enclosure: Explosion Proof Fan cooled
UL: UL Listed; also, UL Certified for Canada CSA: N
CE: N IP Code: 54
Number of Speeds: 1 Hazardous Location: DIV 1 EXP PROOF CL I GR CD CL II GR FG T3B



!
