R859, 75 & 60 HP, 3 Ph, 60 & 50 Hz, 230/460 & 200/400 V, 1200 & 1000 RPM, 280M Frame, TEFC , TerraMAX® Cast Iron Motor, TCA0553AE231GAA009

R859, 75 & 60 HP, 3 Ph, 60 & 50 Hz, 230/460 & 200/400 V, 1200 & 1000 RPM, 280M Frame, TEFC , TerraMAX® Cast Iron Motor, TCA0553AE231GAA009

$13,266.28
(No reviews yet) Write a Review
SKU:
R859
Output HP:
75 Hp
Output KW:
55 kW
Voltage:
230/460 V
Phase:
3
Speed (RPM):
1190 rpm
Frame Size:
280M
Mounting:
B3
Enclosure:
Totally Enclosed Fan Cooled
Product Drawings1:
R859.pdf
Manufacture:
Marathon
Adding to cart… The item has been added

Nameplate Specifications

Phase: 3 Output HP: 75 & 60 Hp
Output KW: 55.0 & 45.0 kW Voltage: 230/460 & 200/400 V
Speed: 1190 & 990 rpm Service Factor: 1.15 & 1.15
Frame: 280M Thermal Protection: No Protection
Efficiency: 94.5 & 93.7 % Ambient Temperature: 40 °C
Frequency: 60 & 50 Hz Current: 174/87 & 166/83 A
Power Factor: 84 Duty: Continuous
Insulation Class: F Design Code: N (IEC)
KVA Code: G Drive End Bearing Size: 6317
Opp Drive End Bearing Size: 6317 Enclosure: Totally Enclosed Fan Cooled
UL: Recognized CSA: N
CE: Y IP Code: 55
Number of Speeds: 1



!
