Nameplate Specifications
| Phase: 3 | Output HP: 20 Hp |
| Output KW: 14.9 kW | Voltage: 230/460 V |
| Speed: 1175 rpm | Service Factor: 1.15 |
| Frame: 286HPV | Thermal Protection: No Protection |
| Efficiency: 92.1 % | Ambient Temperature: 40 °C |
| Frequency: 60 Hz | Current: 53.5/26.7 A |
| Power Factor: 76.5 | Duty: Continuous |
| Insulation Class: F | Design Code: B |
| KVA Code: G | Drive End Bearing Size: 6311 |
| Opp Drive End Bearing Size: 6210 | Enclosure: Totally Enclosed Fan Cooled |
| UL: Recognized | CSA: Y |
| CE: Y | IP Code: 43 |
| Number of Speeds: 1 |
