Nameplate Specifications
| Phase: | 3 | Output HP: | 5 & 3 Hp |
| Output KW: | 3.7 & 2.2 kW | Voltage: | 208-230/460 & 190/380 V |
| Speed: | 3500 & 2925 rpm | Service Factor: | 1.15 & 1.15 |
| Frame: | 182JMV | Enclosure: | Drip Proof |
| Thermal Protection: | No Protection | Efficiency: | 86.5 & 85.5 % |
| Ambient Temperature: | 40 °C | Frequency: | 60 & 50 Hz |
| Current: | 13.6-12.4/6.2 & 9.8/4.9 A | Power Factor: | 86 |
| Duty: | Continuous | Insulation Class: | F |
| Design Code: | B | KVA Code: | J |
| Drive End Bearing Size: | 6207 | Opp Drive End Bearing Size: | 6205 |
| UL: | Recognized | CSA: | Y |
| CE: | Y | IP Code: | 12 |
