Nameplate Specifications
| Phase: 3 | Output HP: 3 Hp |
| Output KW: 2.2 kW | Voltage: 575 V |
| Speed: 1185 rpm | Service Factor: 1.15 |
| Frame: 213JP | Thermal Protection: No Protection |
| Efficiency: 89.5 % | Ambient Temperature: 40 °C |
| Frequency: 60 Hz | Current: 3.5 A |
| Power Factor: 73 | Duty: Continuous |
| Insulation Class: F | Design Code: B |
| KVA Code: J | Drive End Bearing Size: 6309 |
| Opp Drive End Bearing Size: 6206 | Enclosure: Totally Enclosed Fan Cooled |
| UL: Listed | CSA: Y |
| CE: Y | IP Code: 43 |
| Number of Speeds: 1 | Hazardous Location: DIVISION 2 T2B |
