Nameplate Specifications
| Phase: | 3 | Output HP: | 1.50 & 1 Hp |
| Output KW: | 1.1 & 0.75 kW | Voltage: | 230/460 & 190/380 V |
| Speed: | 1175 & 980 rpm | Service Factor: | 1.15 & 1.15 |
| Frame: | 182JM | Enclosure: | Totally Enclosed Fan Cooled |
| Thermal Protection: | No Protection | Efficiency: | 87.5 & 82.5 % |
| Ambient Temperature: | 40 °C | Frequency: | 60 & 50 Hz |
| Current: | 4.6/2.3 & 4.5/2.25 A | Power Factor: | 70 |
| Duty: | Continuous | Insulation Class: | F |
| Design Code: | A | KVA Code: | N |
| Drive End Bearing Size: | 6307 | Opp Drive End Bearing Size: | 6205 |
| UL: | Listed | CSA: | Y |
| CE: | Y | IP Code: | 43 |
| Number of Speeds: | 1 | Hazardous Location: | DIVISION 2 T2B |
