GT1505, 1.50 & 1 HP, 3 Ph, 60 & 50 Hz, 230/460 & 190/380 V, 1200 & 1000 RPM, 182T Frame, TEFC, Globetrotter® General Purpose Motor, 182TTFBD6080

GT1505, 1.50 & 1 HP, 3 Ph, 60 & 50 Hz, 230/460 & 190/380 V, 1200 & 1000 RPM, 182T Frame, TEFC, Globetrotter® General Purpose Motor, 182TTFBD6080

$506.30
(No reviews yet) Write a Review
SKU:
GT1505
Output HP:
1.5 Hp
Output KW:
1.1 kW
Voltage:
230/460 V
Phase:
3
Speed (RPM):
1175 rpm
Frame Size:
182T
Mounting:
Rigid Base
Enclosure:
Totally Enclosed Fan Cooled
Product Drawings1:
GT1505.pdf
Manufacture:
Marathon
Adding to cart… The item has been added

Nameplate Specifications

Phase: 3 Output HP: 1.50 & 1 Hp
Output KW: 1.1 & 0.75 kW Voltage: 230/460 & 190/380 V
Speed: 1175 & 980 rpm Service Factor: 1.15 & 1.15
Frame: 182T Thermal Protection: No Protection
Efficiency: 87.5 & 82.5 % Ambient Temperature: 40 °C
Frequency: 60 & 50 Hz Current: 4.6/2.3 & 4.5/2.25 A
Power Factor: 70 Duty: Continuous
Insulation Class: F Design Code: A
KVA Code: N Drive End Bearing Size: 6206
Opp Drive End Bearing Size: 6205 Enclosure: Totally Enclosed Fan Cooled
UL: Listed CSA: Y
CE: Y IP Code: 43
Number of Speeds: 1 Hazardous Location: DIVISION 2 T2B



!
