Nameplate Specifications
| Phase: | 3 | Output HP: | 75 Hp |
| Output KW: | 56.0 kW | Voltage: | 575 V |
| Speed: | 3570 rpm | Service Factor: | 1.15 |
| Frame: | 365TS | Enclosure: | Totally Enclosed Fan Cooled |
| Thermal Protection: | No Protection | Efficiency: | 94.5 % |
| Ambient Temperature: | 40 °C | Frequency: | 60 Hz |
| Current: | 67.0 A | Power Factor: | 89 |
| Duty: | Continuous | Insulation Class: | F |
| Design Code: | B | KVA Code: | G |
| Drive End Bearing Size: | 6313 | Opp Drive End Bearing Size: | 6213 |
| UL: | Listed | CSA: | Y |
| CE: | Y | IP Code: | 55 |
| Number of Speeds: | 1 | Hazardous Location: | DIVISION 2 T2B |
