GT0310, 3 & 2 HP, 3 Ph, 60 & 50 Hz, 230/460 & 190/380 V, 1800 & 1500 RPM, 182TC Frame, DP, Globetrotter® General Purpose Motor, 182TTDBD6029

GT0310, 3 & 2 HP, 3 Ph, 60 & 50 Hz, 230/460 & 190/380 V, 1800 & 1500 RPM, 182TC Frame, DP, Globetrotter® General Purpose Motor, 182TTDBD6029

$478.24
(No reviews yet) Write a Review
SKU:
GT0310
Output HP:
3 Hp
Output KW:
2.2 kW
Voltage:
230/460 V
Phase:
3
Speed (RPM):
1770 rpm
Frame Size:
182TC
Mounting:
Round
Enclosure:
Drip Proof
Product Drawings1:
GT0310.pdf
Manufacture:
Marathon
Adding to cart… The item has been added

Nameplate Specifications

Phase: 3 Output HP: 3 & 2 Hp
Output KW: 2.2 & 1.5 kW Voltage: 230/460 & 190/380 V
Speed: 1770 & 1475 rpm Service Factor: 1.15 & 1.15
Frame: 182TC Thermal Protection: No Protection
Efficiency: 89.5 & 88.5 % Ambient Temperature: 40 °C
Frequency: 60 & 50 Hz Current: 8/4 & 6.8/3.4 A
Power Factor: 77.5 Duty: Continuous
Insulation Class: F Design Code: A
KVA Code: L Drive End Bearing Size: 6206
Opp Drive End Bearing Size: 6203 Enclosure: Drip Proof
UL: Recognized CSA: Y
CE: Y IP Code: 22
Number of Speeds: 1



!
