GT0265, 25 & 20 HP, 3 Ph, 60 & 50 Hz, 230/460 & 190/380 V, 1800 & 1500 RPM, 284TC Frame, DP, Globetrotter® General Purpose Motor, 284TTDBD6028

GT0265, 25 & 20 HP, 3 Ph, 60 & 50 Hz, 230/460 & 190/380 V, 1800 & 1500 RPM, 284TC Frame, DP, Globetrotter® General Purpose Motor, 284TTDBD6028

$1,981.28
(No reviews yet) Write a Review
SKU:
GT0265
Output HP:
25 Hp
Output KW:
18.7 kW
Voltage:
230/460 V
Phase:
3
Speed (RPM):
1775 rpm
Frame Size:
284TC
Mounting:
Rigid Base
Enclosure:
Drip Proof
Product Drawings1:
GT0265.pdf
Manufacture:
Marathon
Adding to cart… The item has been added

Nameplate Specifications

Phase: 3 Output HP: 25 & 20 Hp
Output KW: 18.7 & 14.9 kW Voltage: 230/460 & 190/380 V
Speed: 1775 & 1475 rpm Service Factor: 1.15 & 1.15
Frame: 284TC Thermal Protection: No Protection
Efficiency: 93.6 & 92.6 % Ambient Temperature: 40 °C
Frequency: 60 & 50 Hz Current: 63/31.5 & 61/30.5 A
Power Factor: 80 Duty: Continuous
Insulation Class: F Design Code: B
KVA Code: G Drive End Bearing Size: 6311
Opp Drive End Bearing Size: 6210 Enclosure: Drip Proof
UL: Recognized CSA: Y
CE: Y IP Code: 22
Number of Speeds: 1



!
