Nameplate Specifications
| Phase: 3 | Output HP: 10 Hp |
| Output KW: 7.5 kW | Voltage: 575 V |
| Speed: 1768 rpm | Service Factor: 1.15 |
| Frame: 215T | Thermal Protection: No Protection |
| Efficiency: 91.7 % | Ambient Temperature: 40 °C |
| Frequency: 60 Hz | Current: 10.2 A |
| Power Factor: 80.1 | Duty: Continuous |
| Insulation Class: F | Design Code: B |
| KVA Code: H | Drive End Bearing Size: 6307 |
| Opp Drive End Bearing Size: 6206 | Enclosure: Drip Proof |
| UL: Recognized | CSA: Y |
| CE: Y | IP Code: 22 |
| Number of Speeds: 1 |
