GT0112, 5 HP, 3 Ph, 60 Hz, 575 V, 3600 RPM, 182T Frame, DP, Globetrotter® General Purpose Motor, 182TTDBD6005

GT0112, 5 HP, 3 Ph, 60 Hz, 575 V, 3600 RPM, 182T Frame, DP, Globetrotter® General Purpose Motor, 182TTDBD6005

$502.03
(No reviews yet) Write a Review
SKU:
GT0112
Output HP:
5 Hp
Output KW:
3.7 kW
Voltage:
575 V
Phase:
3
Speed (RPM):
3510 rpm
Frame Size:
182T
Mounting:
Rigid Base
Enclosure:
Drip Proof
Product Drawings1:
GT0112.pdf
Manufacture:
Marathon
Adding to cart… The item has been added

Nameplate Specifications

Phase: 3 Output HP: 5 Hp
Output KW: 3.7 kW Voltage: 575 V
Speed: 3510 rpm Service Factor: 1.15
Frame: 182T Thermal Protection: No Protection
Efficiency: 86.5 % Ambient Temperature: 40 °C
Frequency: 60 Hz Current: 5.3 A
Power Factor: 82 Duty: Continuous
Insulation Class: F Design Code: A
KVA Code: K Drive End Bearing Size: 6206
Opp Drive End Bearing Size: 6203 Enclosure: Drip Proof
UL: Recognized CSA: Y
CE: Y IP Code: 22
Number of Speeds: 1



!
