Nameplate Specifications
| Phase: | 3 | Output HP: | 3 & 2 Hp |
| Output KW: | 2.2 & 1.5 kW | Voltage: | 230/460 & 190/380 V |
| Speed: | 1183 & 986 rpm | Service Factor: | 1.15 & 1.15 |
| Frame: | 213T | Enclosure: | Drip Proof |
| Thermal Protection: | No Protection | Efficiency: | 88.5 & 88.5 % |
| Ambient Temperature: | 40 °C | Frequency: | 60 & 50 Hz |
| Current: | 8.4/4.2 & 7.2/3.6 A | Power Factor: | 75 |
| Duty: | Continuous | Insulation Class: | F |
| Design Code: | B | KVA Code: | K |
| Drive End Bearing Size: | 6307 | Opp Drive End Bearing Size: | 6206 |
| UL: | Recognized | CSA: | Y |
| CE: | Y | IP Code: | 22 |
| Number of Speeds: | 1 |
