E584, 150 HP, 3 Ph, 60 Hz, 460 V, 3600 RPM, 445TS Frame, EPFC, Hazardous Duty® Explosion Proof Motor, 445TSTGN16505

E584, 150 HP, 3 Ph, 60 Hz, 460 V, 3600 RPM, 445TS Frame, EPFC, Hazardous Duty® Explosion Proof Motor, 445TSTGN16505

$18,528.75
(No reviews yet) Write a Review
SKU:
E584
Output HP:
150 Hp
Output KW:
112 kW
Voltage:
460 V
Phase:
3
Speed (RPM):
3575 rpm
Frame Size:
445TS
Mounting:
Rigid Base
Enclosure:
Explosion Proof Fan Cooled
Product Drawings1:
E584.pdf
Manufacture:
Marathon
Adding to cart… The item has been added

Nameplate Specifications

Phase: 3 Output HP: 150 Hp
Output KW: 112 kW Voltage: 460 V
Speed: 3575 rpm Service Factor: 1.15
Frame: 445TS Thermal Protection: Thermostat
Efficiency: 95.8 % Ambient Temperature: 40 °C
Frequency: 60 Hz Current: 168 A
Power Factor: 88 Duty: Continuous
Insulation Class: F Design Code: B
KVA Code: G Drive End Bearing Size: 6313
Opp Drive End Bearing Size: 6313 Enclosure: Explosion Proof Fan cooled
UL: Listed CSA: N
CE: N IP Code: 54
Number of Speeds: 1 Hazardous Location: DIV 1 EXP PROOF CL I GR CD CL II GR FG T3B



!
