C369B, 5 HP, 3 Ph, 60 Hz, 575 V, 1800 RPM, 184TC Frame, EPFC, Hazardous Duty® Explosion Proof Motor, 184TTGCD6537AA

C369B, 5 HP, 3 Ph, 60 Hz, 575 V, 1800 RPM, 184TC Frame, EPFC, Hazardous Duty® Explosion Proof Motor, 184TTGCD6537AA

$1,818.00
(No reviews yet) Write a Review
SKU:
C369B
Output HP:
5 Hp
Output KW:
3.7 kW
Voltage:
575 V
Phase:
3
Speed (RPM):
1755 rpm
Frame Size:
184TC
Mounting:
Rigid Base
Enclosure:
Explosion Proof Fan Cooled
Product Drawings1:
C369B.pdf
Adding to cart… The item has been added

Nameplate Specifications

Phase: 3 Output HP: 5 Hp
Output KW: 3.7 kW Voltage: 575 V
Speed: 1755 rpm Service Factor: 1
Frame: 184TC Thermal Protection: Thermostat
Efficiency: 89.5 % Ambient Temperature: 50 °C
Frequency: 60 Hz Current: 5.2 A
Power Factor: 80 Duty: Continuous
Insulation Class: F Design Code: B
KVA Code: J Drive End Bearing Size: 6207
Opp Drive End Bearing Size: 6206 Enclosure: Explosion Proof Fan cooled
UL: UL Listed And CSA Certified CSA: Y
CE: N IP Code: 54
Number of Speeds: 1 Hazardous Location: DIV 1 EXP PROOF CL I GR CD CL II GR FG T3C
!
