Product Description
Nameplate Specifications
| Phase: 3 | Output HP: 3 Hp |
| Output KW: 2.2 kW | Voltage: 460 V |
| Speed: 1770 rpm | Service Factor: 1.15 |
| Frame: 182T | Thermal Protection: No Protection |
| Efficiency: 89.5 % | Ambient Temperature: 40 °C |
| Frequency: 60 Hz | Current: 3.9 A |
| Power Factor: 80 | Duty: Continuous |
| Insulation Class: H | Design Code: B |
| KVA Code: K | Drive End Bearing Size: 6206 |
| Opp Drive End Bearing Size: 6205 | Enclosure: Totally Enclosed Non Ventilated |
| UL: Listed | CSA: Y |
| CE: Y | IP Code: 56 |
| Number of Speeds: 1 | Hazardous Location: DIVISION 2 T2B |
Product Videos
Custom Field
Output HP 3 Hp
Output KW 2.2 kW
Voltage 460 V
Phase 3
Speed (RPM) 1770 rpm
Frame Size 182T
Mounting Rigid Base
Enclosure Totally Enclosed Non Ventilated
Product Drawings1 W519A.pdf
