Product Description
Nameplate Specifications
| Phase: 3 | Output HP: 350 & 300 Hp |
| Output KW: 260.0 & 224.0 kW | Voltage: 460 & 380 V |
| Speed: 3579 & 2978 rpm | Service Factor: 1.15 & 1.15 |
| Frame: 447TS | Thermal Protection: No Protection |
| Efficiency: 95.4 & 95.2 % | Ambient Temperature: 40 °C |
| Frequency: 60 & 50 Hz | Current: 373 & 387 A |
| Power Factor: 91.9 | Duty: Continuous |
| Insulation Class: F | Design Code: B |
| KVA Code: G | Drive End Bearing Size: 6314 |
| Opp Drive End Bearing Size: 6314 | Enclosure: Drip Proof |
| UL: Recognized | CSA: Y |
| CE: Y | IP Code: 22 |
| Number of Speeds: 1 |
Product Videos
Custom Field
Output HP 350 Hp
Output KW 260 kW
Voltage 460 V
Phase 3
Speed (RPM) 3579 rpm
Frame Size 447TS
Mounting Rigid Base
Enclosure Drip Proof
Product Drawings1 GT00029.pdf
