Product Description
Nameplate Specifications
| Phase: 3 | Output HP: 50 & 40 Hp |
| Output KW: 37.0 & 30.0 kW | Voltage: 230/460 & 190/380 V |
| Speed: 1778 & 1478 rpm | Service Factor: 1.15 & 1.15 |
| Frame: 326T | Thermal Protection: No Protection |
| Efficiency: 93 & 92.4 % | Ambient Temperature: 40 °C |
| Frequency: 60 & 50 Hz | Current: 122/61 & 119/59.5 A |
| Power Factor: 82 | Duty: Continuous |
| Insulation Class: F | Design Code: B |
| KVA Code: F | Drive End Bearing Size: 6312 |
| Opp Drive End Bearing Size: 6311 | Enclosure: Totally Enclosed Fan Cooled |
| UL: Listed | CSA: Y |
| CE: Y | IP Code: 43 |
| Number of Speeds: 1 |
Product Videos
Custom Field
Output HP 50 Hp
Output KW 37 kW
Voltage 230/460 V
Phase 3
Speed (RPM) 1778 rpm
Frame Size 326T
Mounting Rigid Base
Enclosure TEFC
Product Drawings1 Y1621.pdf
