Product Description
Nameplate Specifications
| Phase: | 3 | Output HP: | 10 Hp |
| Output KW: | 7.5 kW | Voltage: | 575 V |
| Speed: | 1180 rpm | Service Factor: | 1.15 |
| Frame: | 256T | Enclosure: | Totally Enclosed Fan Cooled |
| Thermal Protection: | No Protection | Efficiency: | 91 % |
| Ambient Temperature: | 40 °C | Frequency: | 60 Hz |
| Current: | 10.3 A | Power Factor: | 80.5 |
| Duty: | Continuous | Insulation Class: | H |
| Design Code: | B | KVA Code: | G |
| Drive End Bearing Size: | 6309 | Opp Drive End Bearing Size: | 6209 |
| UL: | Listed | CSA: | Y |
| CE: | Y | IP Code: | 56 |
| Number of Speeds: | 1 | Hazardous Location: | DIVISION 2 T2B |
Product Videos
Custom Field
Output HP 10 Hp
Output KW 7.5 kW
Voltage 575 V
Phase 3
Speed (RPM) 1180 rpm
Frame Size 256T
Mounting Rigid Base
Enclosure Totally Enclosed Fan Cooled
Product Drawings1 W542A.pdf
