Product Description
Nameplate Specifications
| Phase: 3 | Output HP: 40 Hp |
| Output KW: 30 kW | Voltage: 190/380-400 V |
| Speed: 3555 rpm | Service Factor: 1.15 |
| Frame: 286TS | Thermal Protection: No Protection |
| Efficiency: 91.7 % | Ambient Temperature: 50 °C |
| Frequency: 60 Hz | Current: 114.0/57.0-54.0 A |
| Power Factor: 87 | Duty: Continuous |
| Insulation Class: F | Design Code: B |
| KVA Code: F | Drive End Bearing Size: 6211 |
| Opp Drive End Bearing Size: 6211 | Enclosure: Drip Proof |
| UL: Listed | CSA: Y |
| CE: Y | IP Code: 23 |
| Number of Speeds: 1 |
Product Videos
Custom Field
Output HP 40 Hp
Output KW 30 kW
Voltage 190/380-400 V
Phase 3
Speed (RPM) 3555 rpm
Frame Size 286TS
Mounting Rigid Base
Enclosure Drip Proof
Product Drawings1 U1155.pdf
