Product Description
Nameplate Specifications
| Phase: 3 | Output HP: 100 Hp |
| Output KW: 75 kW | Voltage: 230/460 V |
| Speed: 1785 rpm | Service Factor: 1 |
| Frame: 405TC | Thermal Protection: Thermostat |
| Efficiency: 95.4 % | Ambient Temperature: 40 °C |
| Frequency: 60 Hz | Current: 224.0/112.0 A |
| Power Factor: 87 | Duty: Continuous |
| Insulation Class: H | Design Code: INV |
| KVA Code: K | Drive End Bearing Size: 6316 |
| Opp Drive End Bearing Size: 6314 | Enclosure: Totally Enclosed Blower cooled - Axial |
| UL: Recognized | CSA: Y |
| CE: Y | IP Code: 55 |
| Number of Speeds: 1 |
Product Videos
Custom Field
Output HP 100 Hp
Output KW 75 kW
Voltage 230/460 V
Phase 3
Speed (RPM) 1785 rpm
Frame Size 405TC
Mounting Rigid Base
Enclosure Totally Enclosed Blower Cooled-Axial
Product Drawings1 Y517A.pdf
