Product Description
Nameplate Specifications
| Phase: | 3 | Output HP: | 60 Hp |
| Output KW: | 45.0 kW | Voltage: | 460 V |
| Speed: | 890 rpm | Service Factor: | 1.15 |
| Frame: | 405T | Enclosure: | Totally Enclosed Fan Cooled |
| Thermal Protection: | No Protection | Efficiency: | 93 % |
| Ambient Temperature: | 40 °C | Frequency: | 60 Hz |
| Current: | 82.0 A | Power Factor: | 74 |
| Duty: | Continuous | Insulation Class: | F |
| Design Code: | B | KVA Code: | G |
| Drive End Bearing Size: | 6316 | Opp Drive End Bearing Size: | 6313 |
| UL: | Recognized | CSA: | Y |
| CE: | Y | IP Code: | 56 |
| Number of Speeds: | 1 | Hazardous Location: | DIVISION 2 T2B |
Product Videos
Custom Field
Output HP 60 Hp
Output KW 45 kW
Voltage 460 V
Phase 3
Speed (RPM) 890 rpm
Frame Size 405T
Mounting Rigid Base
Enclosure TEFC
Product Drawings1 W590.pdf
