Product Description
Nameplate Specifications
| Phase: 3 | Output HP: 40 & 30 Hp |
| Output KW: 30.0 & 22.4 kW | Voltage: 230/460 & 190/380 V |
| Speed: 1782 & 1485 rpm | Service Factor: 1.15 & 1.15 |
| Frame: 324T | Thermal Protection: No Protection |
| Efficiency: 94.1 & 94.2 % | Ambient Temperature: 40 °C |
| Frequency: 60 & 50 Hz | Current: 95/47.5 & 87/43.5 A |
| Power Factor: 84 | Duty: Continuous |
| Insulation Class: H | Design Code: B |
| KVA Code: G | Drive End Bearing Size: 6312 |
| Opp Drive End Bearing Size: 6212 | Enclosure: Totally Enclosed Fan Cooled |
| UL: Recognized | CSA: Y |
| CE: Y | IP Code: 55 |
| Number of Speeds: 1 |
Product Videos
Custom Field
Output HP 40 Hp
Output KW 30 kW
Voltage 230/460 V
Phase 3
Speed (RPM) 1782 rpm
Frame Size 324T
Mounting Rigid Base
Enclosure Totally Enclosed Fan Cooled
Product Drawings1 U875B.pdf
