Product Description
Nameplate Specifications
| Phase: | 3 | Output HP: | 40 Hp |
| Output KW: | 30.0 kW | Voltage: | 190/380-400 V |
| Speed: | 1775 rpm | Service Factor: | 1.15 |
| Frame: | 324T | Enclosure: | Drip Proof |
| Thermal Protection: | No Protection | Efficiency: | 93 % |
| Ambient Temperature: | 50 °C | Frequency: | 60 Hz |
| Current: | 114.0/56.5-53.5 A | Power Factor: | 84 |
| Duty: | Continuous | Insulation Class: | F |
| Design Code: | B | KVA Code: | G |
| Drive End Bearing Size: | 6312 | Opp Drive End Bearing Size: | 6311 |
| UL: | Listed | CSA: | Y |
| CE: | Y | IP Code: | 23 |
| Number of Speeds: | 1 |
Product Videos
Custom Field
Output HP 40 Hp
Output KW 30 kW
Voltage 190/380-400 V
Phase 3
Speed (RPM) 1775 rpm
Frame Size 324T
Mounting Rigid Base
Enclosure Drip Proof
Product Drawings1 U511A.pdf
