Product Description
Nameplate Specifications
| Phase: | 3 | Output HP: | 50 Hp |
| Output KW: | 37.0 kW | Voltage: | 230/460 V |
| Speed: | 1182 rpm | Service Factor: | 1 |
| Frame: | 365T | Enclosure: | Explosion Proof Fan cooled |
| Thermal Protection: | Thermostat | Efficiency: | 94.5 % |
| Ambient Temperature: | 50 °C | Frequency: | 60 Hz |
| Current: | 123.0/61.5 A | Power Factor: | 80.5 |
| Duty: | Continuous | Insulation Class: | F |
| Design Code: | B | KVA Code: | G |
| Drive End Bearing Size: | 6314 | Opp Drive End Bearing Size: | 6312 |
| UL: | UL Listed And CSA Certified | CSA: | Y |
| CE: | N | IP Code: | 54 |
| Number of Speeds: | 1 | Hazardous Location: | DIV 1 EXP PROOF CL I GR CD CL II GR FG T3C |
Product Videos
Custom Field
Output HP 50 Hp
Output KW 37 kW
Voltage 230/460 V
Phase 3
Speed (RPM) 1182 rpm
Frame Size 365T
Mounting Rigid Base
Enclosure Explosion Proof Fan cooled
Product Drawings1 E571.pdf
