Product Description
Nameplate Specifications
| Phase: | 1 | Output HP: | 1.50 Hp |
| Output KW: | 1.1 kW | Voltage: | 115/208-230 V |
| Speed: | 3450 rpm | Service Factor: | 1.15 |
| Frame: | 56 | Enclosure: | Totally Enclosed Fan Cooled |
| Thermal Protection: | Manual | Efficiency: | 77 % |
| Ambient Temperature: | 40 °C | Frequency: | 60 Hz |
| Current: | 12.0/7.5-6.0 A | Power Factor: | 98 |
| Duty: | Continuous | Insulation Class: | B |
| Design Code: | L | KVA Code: | G |
| Drive End Bearing Size: | 6203 | Opp Drive End Bearing Size: | 6203 |
| UL: | Recognized ( Not Protector) | CSA: | Y |
| CE: | N | IP Code: | 43 |
| Number of Speeds: | 1 |
Product Videos
Custom Field
Output HP 1.5 Hp
Output KW 1.1 kW
Voltage 115/208-230 V
Phase 3
Speed (RPM) 3450 rpm
Frame Size 56
Mounting Rigid Base
Enclosure Totally Enclosed Fan Cooled
Product Drawings1 K332.pdf
