Product Description
Nameplate Specifications
| Phase: | 1 | Output HP: | 0.25 Hp |
| Output KW: | 0.19 kW | Voltage: | 115 V |
| Speed: | 1140 rpm | Service Factor: | 1 |
| Frame: | 56 | Enclosure: | Totally Enclosed Non Ventilated |
| Thermal Protection: | Automatic | Efficiency: | 53 % |
| Ambient Temperature: | 40 °C | Frequency: | 60 Hz |
| Current: | 5.6 A | Power Factor: | 0 |
| Duty: | Continuous | Insulation Class: | B |
| KVA Code: | M | Drive End Bearing Size: | 6203 |
| Opp Drive End Bearing Size: | 6203 | UL: | Recognized |
| CSA: | Yes | CE: | N |
| Number of Speeds: | 1 |
Product Videos
Custom Field
Output HP 0.25 Hp
Output KW 0.19 kW
Voltage 115 V
Phase 1
Speed (RPM) 1140 rpm
Frame Size 56
Mounting Rigid Base
Enclosure TEAO
Product Drawings1 H137.pdf
