Product Description
Nameplate Specifications
| Phase: 3 | Output HP: 25 Hp |
| Output KW: 18.7 kW | Voltage: 200 V |
| Speed: 1775 rpm | Service Factor: 1.15 |
| Frame: 284T | Thermal Protection: No Protection |
| Efficiency: 93.6 % | Ambient Temperature: 40 °C |
| Frequency: 60 Hz | Current: 72.5 A |
| Power Factor: 80 | Duty: Continuous |
| Insulation Class: F | Design Code: B |
| KVA Code: G | Drive End Bearing Size: 6311 |
| Opp Drive End Bearing Size: 6210 | Enclosure: Drip Proof |
| UL: Recognized | CSA: Y |
| CE: Y | IP Code: 22 |
| Number of Speeds: 1 |
Product Videos
Custom Field
Output HP 25 Hp
Output KW 18.7 kW
Voltage 200 V
Phase 3
Speed (RPM) 1775 rpm
Frame Size 284T
Mounting Rigid Base
Enclosure Drip Proof
Product Drawings1 GT0865.pdf
