Product Description
Nameplate Specifications
| Phase: | 1 | Output HP: | 0.33 Hp |
| Output KW: | 0.25 kW | Voltage: | 115 V |
| Speed: | 1725 rpm | Service Factor: | 1.35 |
| Frame: | 48Y | Enclosure: | Drip Proof |
| Thermal Protection: | Automatic | Efficiency: | 57.4 % |
| Ambient Temperature: | 40 °C | Frequency: | 60 Hz |
| Current: | 5.8 A | Power Factor: | 0 |
| Duty: | Continuous | Insulation Class: | B |
| KVA Code: | S | Drive End Bearing Size: | 6203 |
| Opp Drive End Bearing Size: | 6203 | UL: | Recognized |
| CSA: | Yes | CE: | N |
| Number of Speeds: | 1 |
Product Videos
Custom Field
Output HP 0.33 Hp
Output KW 0.25 kW
Voltage 115 V
Phase 1
Speed (RPM) 1725 rpm
Frame Size 48
Mounting PDQ Mounting
Enclosure Drip Proof
Product Drawings1 4731.pdf
