Product Description
Nameplate Specifications
| Phase | 1 | Output HP | 2 Hp |
| Output KW | 1.5 kW | Voltage | 220 V |
| Speed | 1440 rpm | Service Factor | 1 |
| Frame | 182T | Thermal Protection | No Protection |
| Efficiency | 72 % | Ambient Temperature | 40 °C |
| Frequency | 50 Hz | Current | 11.2 A |
| Power Factor | 77 | Duty | Continuous |
| Insulation Class | F | Design Code | NO DESIGN CODE |
| KVA Code | J | Drive End Bearing Size | 6206 |
| Opp Drive End Bearing Size | 6205 | Enclosure | Totally Enclosed Fan Cooled |
| UL | Recognized | CSA | Y |
| CE | Y | IP Code | 44 |
| Number of Speeds | 1 |
Product Videos
Custom Field
Output HP 2 Hp
Output KW 1.5 kW
Voltage 220 V
Phase 1
Speed (RPM) 1440 rpm
Frame Size 182T
Mounting Rigid Base
Enclosure Totally Enclosed Fan Cooled
Product Drawings1 131556.00.pdf
