Product Description
Nameplate Specifications
| Phase: | 1 | Output HP: | 0.33 & 0.13 Hp |
| Output KW: | 0.25 & 0.09 kW | Voltage: | 115 & 115 V |
| Speed: | 1725 & 1150 rpm | Service Factor: | 1.0 & 1.0 |
| Frame: | 48Z | Enclosure: | Totally Enclosed Air Over |
| Thermal Protection: | Automatic | Efficiency: | 64.0 % |
| Ambient Temperature: | 40 °C | Frequency: | 60 & 60 Hz |
| Current: | 5.3 & 2.9 A | Power Factor: | 66 |
| Duty: | Continuous | Insulation Class: | B |
| Design Code: | 2VT | KVA Code: | P |
| Drive End Bearing Size: | 6203 | Opp Drive End Bearing Size: | 6203 |
| UL: | Recognized | CSA: | Y |
| CE: | N | IP Code: | 43 |
| Number of Speeds: | 2 |
Product Videos
Custom Field
Output HP 0.33 & 0.13 Hp
Output KW 0.25 & 0.09 kW
Voltage 115 & 115 V
Phase 1
Speed (RPM) 1725 & 1150 rpm
Frame Size 48Z
Mounting Rigid Base
Enclosure Totally Enclosed Air Over
Product Drawings1 X911.pdf
