Product Description
Nameplate Specifications
| Phase: 3 | Output HP: 3 Hp |
| Output KW: 2.2 kW | Voltage: 230/460 V |
| Speed: 1760 rpm | Service Factor: 1.15 |
| Frame: 182T | Thermal Protection: No Protection |
| Efficiency: 90.2 % | Ambient Temperature: 40 °C |
| Frequency: 60 Hz | Current: 8.0/4.0 A |
| Power Factor: 80 | Duty: Continuous |
| Insulation Class: F | Design Code: B |
| KVA Code: K | Drive End Bearing Size: 6206 |
| Opp Drive End Bearing Size: 6206 | Enclosure: Totally Enclosed Air Over |
| UL: No | CSA: N |
| CE: N | IP Code: 55 |
| Number of Speeds: 1 |
Product Videos
Custom Field
Output HP 3 Hp
Output KW 2.2 kW
Voltage 230/460 V
Phase 3
Speed (RPM) 1760 rpm
Frame Size 182T
Mounting Rigid Base
Enclosure Totally Enclosed Air Over
Product Drawings1 824528.00.pdf
